| amlogic M8 4-core soc key features |
| CPU | S905quad-core cortex-A53 frequency：２.０G |
| GPU | Mali-450 5-Core GPU |
| FLASH | 16GB EMMC OR 8GB EMMC is optional |
| SDRAM | 2GB DDR3 OR 1GB DDR3 |
| Power Supply Specifications |
| ◆Power Supply | DC 5V/2A |
| ◆Power Indicator (LED) | Power ON :blue/green/Grey-green |
| Main Features |
| ◆Case | Plastic material (Private model ) |
| ◆OS | Android5.1 |
| ◆KODI | 16.0 |
| ◆WIFI | 2.4G +5G +Bluetooth/2GB DDR3 OR 2.4GHz/1GB DDR3 |
| ◆Bluetooth | Bluetooth 4.0 |
| ◆3D | Hardward 3D graphics acceleration |
| ◆Support Decoder format | HD MPEG1/2/4,H.264, HD AVC/VC-1,RM/RMVB,Xvid/DivX3/4/5/6 ,RealVideo8/9/10 |
| ◆Support Media format | Avi/Rm/Rmvb/Ts/Vob/Mkv/Mov/ISO/wmv/asf/flv/dat/mpg/mpeg |
| ◆Support Music format | MP3/WMA/AAC/WAV/OGG/AC3/DDP/TrueHD/DTS/DTS/HD/FLAC/APE |
| ◆Support Photo format | HD JPEG/BMP/GIF/PNG/TIFF |
| ◆USB host | 2 High speed USB 2.0,support U DISK and USB HDD |
| ◆Card reader | SD/SDHC/MMC cards |
| ◆HDD file system | FAT16/FAT32/NTFS |
| ◆Support Subtitle | SRT/SMI/SUB/SSA/IDX+USB |
| ◆High Difinition video output | SD/HD max.1920x1080 pixel |
| ◆OSD type of languages | English/French/German/Spanish/Italian/ etc multilateral languages |
| ◆LAN | Ethernet:Gigabit 10/100M/1000M, standard RJ-45 |
| ◆Wireless | Built in WiFi |
| ◆Mouse/ Keyboard | Support mouse and keyboard via USB;Support 2.4GHz wireless mouse and keyboard via 2.4GHz USB dongle |
| ◆HDMI | HDMI2.0up to 4k2k Output |
| ◆4K2k hd decoding | 4k2k H.265 Hardware Video Decode and 4k2k Output |
| ◆1080P | Support |
| ◆AV | Support |
| ◆Dolby | Support |
| ◆3G | Support |
| ◆SPDIF/IEC958 | Coaxial |
| Software Specifications |
| ◆Network Function | Skype chatting,Picasa,Youtube,Flicker,Facebook,Online movies,etc |
| ◆Other feature | Free Internet searching,thousands of android applications,many kinds of games,etc. |
| Payment |
| T/T 30% deposit before production, pay off the balance before the shipment. |
| Leading time |
| 30-35 days after 30% T/T deposit received and the artworks & translation works must be confirmed within one week after deposit made date. |
| sunvell Technolgoy Support |
OEM:
1. logo printing on housing
2. Customize package
3. Software Customization: Booting image, UI, APP, Function… and so on |
ODM:
1. PCBA desgin
2. Housing desgin
3. Software Customization: Booting image, UI, APP, Function… and son on |
