| Hardware Specifications |
| Chipset | Amlogic S912 Octa-Core ARM Cortex-A53 64-bit 2.0GHz |
| GPU | ARM Mali-T820MP3 GPU 750MHZ+ |
| FLASH | 16GB eMMC FLASH |
| SDRAM | 2GB DDR3/DDR4 |
| Power Supply Specifications |
| ◆ Power Supply | DC 5V/2A |
| Main Features |
| ◆OS | Android 6.0 Kikat |
| ◆ Video/Picture Decoding | •VP9-10 Profile-2 up to 4Kx2K@60fps
•H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps
•H.264 AVC HP@L5.1 up to 4Kx2K@30fps, H.264 MVC up to 1080p @60fps
•MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)
•WMV/VC-1 SP/MP/AP up to 1080P@60fps
•AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps
•MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
•MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
•RealVideo 8/9/10 up to 1080P@60fps
•WebM up to VGA
•MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
•Supports JPEG thumbnail, scaling, rotation and transition effects
|
| ◆ Video/Picture Encoding | •Independent JPEG and H.264 encoder with configurable performance/bit-rate
•JPEG image encoding
•H.264 video encoding up to 1080P@60fps with low latency
|
| ◆ Video Post-Processing Engine | HDR10 and HLG HDR processing, motion adaptive 3D noise reduction filter,
advanced motion adaptive edge enhancing de-interlacing engine, 3:2 pull-down support, deblocking filters, etc.. |
| ◆ Video Output | •Built-in HDMI 2.0a transmitter including both controller and PHY with 3D, CEC, HDR and HDCP 2.2, 4Kx2K@60 max resolution output
•CVBS 480i/576i standard definition output
•RGB888 TTL interface up to 1920×1080
|
| ◆Audio Decoder and Input/Output | •Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
•I2S audio interface supporting 8-channel (7.1) input and output
•Built-in serial digital audio SPDIF/IEC958 output and PCM input/output
•Built-in stereo audio DAC
•Dual-channel digital microphone PDM input
•Supports concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM
|
| ◆ USB host | 4High speed USB 2.0,support U DISK and USB HDD |
| ◆ Card reader | SD/SDHC/MMC cards |
| ◆ HDD file system | FAT16/FAT32/NTFS |
| ◆ Support Subtitle | SRT/SMI/SUB/SSA/IDX+USB |
| ◆ High Difinition video output | Support all standard SD/HD/4k2k Ultra HD decoding and output |
| ◆ OSD type of languages | English/French/German/Spanish/Italian/ etc multilateral languages |
| ◆ LAN | Ethernet:IEEE 802.3 10/100/1000M |
| ◆ Wireless | Support 802.11 a/b/g/n/ac, Dual channel WIFI 2.4GHz/5.8GHz |
| ◆ Bluetooth | BT 4.0 |
| ◆ Mouse/ Keyboard | Support mouse and keyboard via USB;Support 2.4GHz wireless mouse and keyboard via 2.4GHz USB dongle |
| ◆ HDMI | HDMI 2.0 |
| ◆ AV | Support |
| Software Specifications |
| ◆ Network Function | Miracast,KODI,Airplay,Skype chatting,Picasa,Youtube,Flicker,Facebook,Online movies,etc. |
| ◆ Other feature | Free Internet searching,thousands of android applications,many kinds of games,etc. |
